PoE	No
SKU	TEG1024D
UPC	885397030133
Brand	Tenda
Color	Black
Model	TEG1024D
Notes	Some technical items (buffer memory, jumbo frame size, and power consumption) vary across listings; values are reported as provided by different sources.
Ports	24
Fanless	true
Category	Networking
Features	Plug-and-play Auto-negotiation Auto MDI/MDIX Store-and-forward switching IEEE 802.3x flow control Fanless, quiet operation Full steel housing with ventilation holes 6 kV lightning protection (ports and power)
Warranty	3 Years (reported)
Port Type	RJ45 (Auto-negotiation, Auto MDI/MDIX)
Stackable	No
Management	Unmanaged (Layer 2)
Description	The Tenda TEG1024D is a 24-port unmanaged Gigabit Ethernet switch designed for SMB, office, surveillance and community networks. It features 24 auto‑negotiation 10/100/1000 Mbps RJ45 ports with Auto MDI/MDIX, store-and-forward switching and IEEE 802.3x flow control for reliable data transfer. The fanless, full-steel housing provides quiet operation and efficient heat dissipation; the compact 1U/13-inch form supports desktop, wall and rack mounting. With a switching capacity of 48 Gbps and a packet forwarding rate around 35.6–35.7 Mpps, the TEG1024D handles high-traffic workloads. The switch includes built-in 6 kV lightning protection for ports and power, certifications including CE/FCC/RoHS, and plug-and-play operation for simple deployment. Package contents reported include the switch, power cord, user manual/quick guide, mounting ears and installation screws.
Form Factor	Desktop / Wall / Rack-mountable (1U)
Item Weight	1.5 pounds (approx.)
Port Speeds	10/100/1000 Mbps per port
Power Input	AC 100–240V, 50/60Hz (internal power supply)
Flow Control	IEEE 802.3X
Manufacturer	Tenda
Sub-Category	Switches and Hubs
VLAN Support	Reported (varies by listing)
Energy Saving	Yes (power-saving features reported)
Product Title	Tenda TEG1024D 24-Port Gigabit Unmanaged Ethernet Switch (48Gbps, Fanless, Metal Housing, 6kV Lightning Protection)
Certifications	CE FCC RoHS
LED Indicators	1 x Power, 24 x Link/Activity
Model Variants	TEG1024D v7 TEG1024D v9
Forwarding Mode	Store-and-forward
Storage Humidity	5% - 90% RH, non-condensing
Country of Origin	China
MAC Address Table	8K entries
Dimensions (WxDxH)	Metric: 294 x 178 x 44 mm Imperial: 17.32 x 7.09 x 1.73 inches
Operating Humidity	10% - 90% RH, non-condensing
Switching Capacity	48 Gbps
Storage Temperature	-40°C to 70°C (reported)
Lightning Protection	6 kV protection for ports and power (reported)
Operating Temperature	0°C to 45°C (reported)
Standards / Protocols	IEEE 802.3 IEEE 802.3u IEEE 802.3ab IEEE 802.3x CSMA/CD
Jumbo Frame (reported)	12 KB (reported by one source) 9 KB (reported by one source)
Packet Forwarding Rate	Approximately 35.6–35.7 Mpps
Housing / Case Material	Metal (full steel housing)
Buffer Memory (reported)	4 MB (reported by one source) 2 Mb (reported by one source) 128 KB (reported by one source)
ESD Protection (reported)	Air Discharge: ±10 kV Contact Discharge: ±8 kV
Per-Port Full-Duplex Rate	Up to 2000 Mbps (1 Gbps full-duplex)
Max Power Consumption (reported)	<12W (reported by multiple sources) ~18W (reported by one source) 20W (reported by one source)
Included Accessories / Package Contents	24-Port Gigabit Switch (TEG1024D) Power cord User manual / Quick installation guide 2 x mounting ears 8 x screws 4 x rubber feet

Tenda TENDA (TEG1024D) 24-port Gigabit Ethernet switch is a supplier-matched product available from Spot IT. Use this item for compatible business, office, and IT requirements. Manufacturer part number: TD82006. Order online for Australia-wide delivery with local support.
