SKU	TEG1005D
UPC	885397271024
Brand	Tenda
Model	TEG1005D
Cooling	Fanless
Category	Networking
Port Type	RJ45
Description	The Tenda TEG1005D is a compact, fanless 5-port Gigabit unmanaged switch in a durable metal housing for desktop or wall mounting. It provides five 10/100/1000 Mbps auto-negotiation RJ45 ports with auto MDI/MDIX, wire-speed forwarding, IEEE 802.3X flow control and support for jumbo frames (up to 15KB) for improved large-file and video transmission. Built for reliable 24/7 operation, the switch features 6KV lightning protection on all ports, low power consumption (~2.5W), and comes with an external 5V DC, 0.6A power adapter and quick installation guide. Plug-and-play operation requires no configuration, making it suitable for home, small office and surveillance deployments.
Duplex Mode	Full-duplex
Form Factor	Desktop; Wall-mountable
Item Weight	0.305 kg (0.67 lb)
PoE Support	No
Port Speeds	10/100/1000 Mbps (Gigabit)
Flow Control	IEEE 802.3X
Manufacturer	Tenda
Sub-Category	Switches and Hubs
Auto MDI/MDIX	Yes
Case Material	Metal (galvanized steel, ~0.8 mm)
Compatibility	PCs, laptops, routers, printers, IP cameras, game consoles, smart TVs, mesh systems (Ethernet-enabled devices)
Port Features	Auto-negotiation, Auto MDI/MDIX, LED status indicators
Product Title	Tenda TEG1005D 5-Port Gigabit Unmanaged Desktop/Wall-Mount Switch
Certifications	CE, FCC, RoHS
LED Indicators	1 x Power, 5 x Link/Activity
Forwarding Mode	Store-and-Forward
Forwarding Rate	7.44 Mpps
Layer Supported	Layer 2
Number of Ports	5
Power Input (AC)	100–240V AC, 50/60 Hz
Storage Humidity	5%–90% RH (non-condensing)
Switching Method	Store-and-Forward
Country of Origin	China
MAC Address Table	2K entries
Power Consumption	≈2.5 W
Switch Management	Unmanaged
Operating Humidity	10%–90% RH (non-condensing)
Switching Capacity	10 Gbps
Included Components	TEG1005D switch, 5V 0.6A power adapter, instruction/quick installation guide
Jumbo Frame Support	Up to 15KB
Storage Temperature	-40°C to 70°C
Lightning Protection	6KV on all ports
Power Adapter Output	5V DC, 0.6A (external)
Operating Temperature	0°C to 45°C
Dimensions (W x D x H)	100 x 64 x 23 mm (3.94 x 2.52 x 0.91 in)
Standards and Protocols	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x
Maximum Data Rate (per port)	1000 Mbps

Tenda TENDA (TEG1005D) 5-port Gigabit Desktop switch is a supplier-matched product available from Spot IT. Use this item for compatible business, office, and IT requirements. Manufacturer part number: TD82004. Order online for Australia-wide delivery with local support.
