Tenda (Tef1110P-8-102W) 8-Port 10/100Mbps + 2 Gigabit Desktop Switch With 8-Port PoE+ TEF1110P-8-102W
$145.00
| SKU: | 385043 |
|---|---|
| MPN: | TEF1110P-8-102W Link |
| Manufacturer: | https://www.tenda.com |
| Brand: | Tenda |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | Preorder 2-3 weeks |
| Fright Estimate |
Description
▼
Tenda TEF1110P-8-102W 8-Port 10/100Mbps + 2 Gigabit Desktop Switch With 8-Port PoE+
Specifications
▼
| SKU | TEF1110P-8-102W |
|---|---|
| MTBF | >= 50,000 hours |
| Type | Desktop PoE+ Switch |
| Brand | Tenda |
| Color | Black |
| Model | TEF1110P-8-102W |
| Weight | Approximately 1,470 g |
| Category | Networking |
| Mounting | Desktop (supports wall mounting); not rack-mountable |
| PoE Type | End-span (specified lines/pairs in documentation) |
| PoE Ports | 8 x 10/100 Mbps (Data + Power) |
| Indicators | Link/Act, PoE Status, Power, 1000M (per-port LEDs + power LED) |
| Protection | 6 kV lightning protection (ports and power); ESD: air ±10 kV, contact ±8 kV (as specified) |
| Buffer Size | 448 KB |
| Description | Compact 10-port desktop PoE+ switch designed for IP camera and monitoring deployments. Provides eight 10/100 Mbps PoE/PoE+ ports (IEEE 802.3af/at) with per-port up to 30W and a total PoE budget of 99W, plus two gigabit uplink ports (10/100/1000). Features Tenda's extended-transmission mode for up to 250 m over twisted pair, 6 kV lightning protection, VLAN/Extend/Default operating modes, 5.6 Gbps switching capacity and store-and-forward forwarding for reliable, long-distance monitoring networks. Includes power adapter and quick installation guide. |
| Port Speeds | 8 ports: 10/100 Mbps; 2 ports: 10/100/1000 Mbps |
| Power Input | AC 100–240V 50/60Hz; DC adapter 51V (adapter current specified as 2.0–2.1A in sources) |
| Sub-Category | Switches and Hubs |
| Uplink Ports | 2 x 10/100/1000 Mbps (Gigabit) |
| PoE Standards | IEEE 802.3af, IEEE 802.3at |
| Power Adapter | Included (51V DC, ~2A as specified by manufacturer sources) |
| Product Title | Tenda TEF1110P-8-102W 10-Port Desktop PoE+ Switch (8x 10/100 PoE, 2x Gigabit Uplink, 99W) |
| Certifications | CE, FCC, RoHS, 3C (as specified) |
| Port Interface | RJ45 |
| Forwarding Mode | Store-and-forward |
| Forwarding Rate | 1.48 Mpps |
| Number of Ports | 10 |
| Package Contents | 8-Port 10/100 Mbps PoE Switch + 2 Gigabit uplink ports (TEF1110P-8-102W), Power Adapter, Quick Installation Guide |
| PoE Total Budget | 99W |
| Storage Humidity | 5%–90% non-condensing |
| Country of Origin | China |
| MAC Address Table | 16K entries |
| Operating Humidity | 10%–90% non-condensing |
| Switching Capacity | 5.6 Gbps |
| Storage Temperature | -40°C to 70°C |
| Included Accessories | Power adapter, Quick installation guide |
| PoE Power (Per Port) | Up to 30W (802.3at) |
| VLAN/Operating Modes | Default Mode, VLAN Mode (ports 1-8 isolated, can connect to uplinks), Extend Mode (up to 250 m at 10 Mbps) |
| Extended Transmission | Up to 250 m over twisted pair (Extend mode, 10 Mbps) |
| Operating Temperature | 0°C to 45°C (sources specify 0–40°C or 0–45°C) |
| Standards & Protocols | IEEE 802.3, IEEE 802.3u, IEEE 802.3x, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at |
| Dimensions (W x D x H) | 177.5 x 104 x 26 mm |
| PoE Power (Per Port, 802.3af) | 15.4W (802.3af) |
