Tenda (Tef1105P-4-63W) 5-Port 10/100Mbps Desktop Switch With 4-Port PoE+ TEF1105P-4-63W
$51.00
| SKU: | 298168 |
|---|---|
| MPN: | TEF1105P-4-63W Link |
| Manufacturer: | https://www.tenda.com |
| Brand: | Tenda |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
Tenda TEF1105P-4-63W 5-Port 10/100Mbps Desktop Switch with 4-Port PoE+
Specifications
▼
| Brand | Tenda |
|---|---|
| Color | Black |
| Model | TEF1105P-4-63W |
| Ports | 5 x 10/100Base-TX RJ45 |
| UNSPSC | 43222612 |
| Mounting | Desktop Wall |
| PoE Modes | Standard; Extend (Extend mode: up to 250 m at 10 Mbps) |
| PoE Ports | 4 (Ports 1-4) |
| Manageable | No (unmanaged) |
| Buffer Size | 448K |
| Description | Compact unmanaged Fast Ethernet switch designed for WLAN and IP surveillance. Provides 5 x 10/100 Mbps RJ45 ports (4 x PoE+ data/power ports and 1 x data-only uplink), supports IEEE 802.3af/at (PoE/PoE+) with up to 30 W per port and 58 W total. Features two operating modes (Standard and Extend) — Extend mode enables data and power transmission up to 250 m (at 10 Mbps). Built-in 6 kV lightning protection (ports and power) and ESD protection help protect outdoor or elevated deployments. Store-and-forward switching, desktop or wall-mountable, compact footprint, suitable for powering APs, IP cameras and other PoE devices. |
| Form Factor | Desktop |
| Power Input | 100–240 V AC, 50/60 Hz (via power adapter); adapter output: 51 V DC, 1.25 A |
| Uplink Port | 1 x 10/100 Mbps |
| Manufacturer | Tenda Technology |
| Port Details | 4 x 10/100Base-TX PoE+ (data + power), 1 x 10/100Base-TX data-only uplink |
| Power Source | Power Adapter |
| Product Line | TEF11 series |
| PoE Standards | IEEE 802.3af (PoE) IEEE 802.3at (PoE+) |
| Product Title | Tenda TEF1105P-4-63W 5-Port 10/100Mbps Desktop PoE Switch (4x PoE+, 58W, 6 kV) |
| Certifications | FCC CE RoHS |
| LED Indicators | 5 x Link/Ack LEDs; 1 x Power LED |
| Rack Mountable | No |
| Transfer Speed | 10/100 Mbps |
| Forwarding Mode | Store-and-forward |
| Layer Supported | Layer 2 |
| Datasheet Update | 2025-06-05 |
| Storage Humidity | 5%–90% non-condensing |
| Country of Origin | China |
| MAC Address Table | 1K entries |
| Network Standards | IEEE 802.3 IEEE 802.3u IEEE 802.3x IEEE 802.3af IEEE 802.3at |
| Recommended Cable | CAT5/5e UTP or better |
| Network Technology | 10/100Base-TX (Fast Ethernet) |
| Operating Humidity | 10%–90% non-condensing |
| Switching Capacity | 1 Gbps |
| Storage Temperature | -40 °C to 70 °C |
| Dimensions (W×D×H) | 100 × 100 × 26 mm (3.9 × 3.9 × 1 in) |
| Lightning Protection | 6 kV (ports and power); ESD: Air ±10 kV, Contact ±8 kV |
| Media Type Supported | Twisted Pair |
| Operating Temperature | 0 °C to 45 °C |
| Packet Forwarding Rate | 0.74 Mpps |
| Manufacturer Part Number | TEF1105P-4-63W |
| PoE Power per Port (max) | 30 W |
| PoE Total Power (budget) | 58 W |
| Weight (shipping listed) | 1.46 lb |
| Max Transmission Distance | Up to 250 meters (Extend Mode, 10 Mbps); standard Ethernet up to 100 m |
