Brand	Cisco
Model	SFP-10G-SR
DDM/DOM	Supported (SFF-8472)
TX Power	-7.3 to -1 dBm
Warranty	Vendor-dependent (examples from sources: limited lifetime, 3-year, 5-year warranties reported)
Connector	Duplex LC
Core Size	50/125 µm
Fiber Type	Multimode Fiber (MMF)
Modulation	NRZ
Wavelength	850 nm
Description	10GBASE-SR SFP+ multimode fiber transceiver (SFP-10G-SR) delivers 10Gbps class connectivity over MMF using an 850 nm VCSEL transmitter and duplex LC interface. Supports short-range links up to 300 m on OM3 and up to 400 m on OM4 (SFF/IEEE compliant), features digital diagnostics (DDM/DOM), low power consumption (≤1W) and hot-swappable SFP+ form factor — ideal for data centers, enterprise wiring closets, SAN and high-performance networking applications. Compatible with Cisco OEM and many third-party SFP+ ports; vendor-specific warranties and packaging vary.
Form Factor	SFP+
Power Budget	3.8 dB
Hot-swappable	Yes
Max Data Rate	10.3125 Gbps (10G class)
Product Title	Cisco 10GBASE-SR SFP+ Transceiver 850nm MMF Duplex LC (SFP-10G-SR)
Receiver Type	PIN
Extinction Ratio	>3 dB
Package Contents	Typically sold as a single SFP+ transceiver module (1x module); exact contents vary by vendor.
Transmitter Type	VCSEL
Nominal Data Rate	10 Gbps
Receiver Overload	-1 dBm
Receiver Sensitivity	< -11.1 dBm
Typical Applications	Data center 10 Gigabit Ethernet links Enterprise wiring closets Storage Area Network (SAN) High Performance Computing (HPC)
Compatibility / Notes	Designed as Cisco 10GBASE-SR (SFP-10G-SR). Widely available as OEM and third-party compatible modules (examples: FluxLight, 10Gtek, FS, Crestron). Compatible with many SFP+ ports including Cisco, Meraki (MA-SFP-10GB-SR), Ubiquiti (UF-MM-10G), Fortinet, Mikrotik, Netgear, D-Link, Supermicro, TP-Link and Crestron DMF/DMCF series (compatibility may vary by vendor/device and firmware).
Max Power Consumption	≤1 W
Operating Temperature	0 to 70 °C (32 to 158 °F)
Standards / Compliance	IEEE 802.3ae SFF-8431 SFF-8432 SFF-8472 SFP+ MSA CPRI / eCPRI (per vendor listings)
Maximum Transmission Distance	Up to 300 m on OM3; up to 400 m on OM4 (sources also reference 26 m on legacy FDDI/standard MMF)
Additional Vendor-specific Specs (from partner listings)	Diagnostics: Digital Diagnostics Monitoring via 2-wire serial interface (SFF-8472) Compliance Notes: MSA-compliant; SFF and IEEE specifications as listed above Reach (reported variants): 300 m @ OM3 / 400 m @ OM4; some vendor listings note 300 m DOM/300 m reach; one legacy note: 26 m on standard FDDI Form Factor (reported by vendors): SFP+
