Brand	Eaton
Model	9SX1500I-AU
Series	9SX
Weight	18.5 kg
Topology	Online / Double-conversion
Warranty	Limited warranty - 2 years
Description	The Eaton 9SX1500I-AU is an online double-conversion UPS designed for high-availability protection of servers, storage, network and telecom equipment. Delivering 1500 VA / 1350 W with a power factor of 0.9, it features advanced battery management (ABM) with hot-swappable sealed lead-acid batteries, selectable high-efficiency mode, multilingual graphical LCD, and remote management interfaces (USB, RS-232, EPO and relay mini terminal blocks). A single expansion slot accepts optional network/management cards for SNMP/modbus and relay functions. Compact tower form factor with 160 x 437 x 252 mm footprint and 18.5 kg weight.
Form Factor	Tower
Battery Type	Sealed lead-acid (internal)
Phase (Input)	Single-phase
Product Title	Eaton 9SX 1500VA (1350W) Online Tower UPS - 9SX1500I-AU (240V, 4x AU 10A)
Acoustic Noise	<= 43 dB at 1 m
Phase (Output)	Single-phase
Input Connector	1 x IEC 60320 C14
Output Features	Generator compatible True online double-conversion with high power density Remote on/off control (ROO) and Remote Power Off (RPO)
Output Waveform	Sine wave
Additional Notes	Built-in internal battery pack included One slot for optional communication/network card (card not included) Designed for network, IT, telecom, storage, industrial and medical equipment protection
Output Frequency	50/60 Hz (selectable)
Run Time (Up To)	~5 minutes at full load (typical)
Output Connectors	4 x Australian 10A (AUS 10A)
Power Capacity VA	1500 VA
Relative Humidity	0–96% non-condensing
Battery Management	ABM advanced battery management to extend battery life and optimize recharge; firmware upgradable
Altitude / Derating	<1000 m for nominal power; ~10% power reduction every 1000 m up to 3000 m
Input Voltage Range	190–276 V AC without derating (up to 120–276 V AC with derating)
Output Power Factor	0.9
Display / Indicators	Multilingual graphical LCD display; LED indicators
Power Capacity Watts	1350 W
Input Frequency Range	40–70 Hz
Nominal Input Voltage	240 V AC
Operating Temperature	0° to 40°C
Catalog / Part Numbers	9SX1500I-AU 78020088 444136 PW86362 9SX1500IAU
Dimensions (W x D x H)	160 x 437 x 252 mm
Output Nominal Voltage	240 V AC
Software Compatibility	Eaton Intelligent Power Manager Eaton Intelligent Power Protector
Input Voltage Supported	AC 200/208/220/230/240 V
Network / Expansion Slot	1 expansion slot for optional Network-M2, Network-MS, ModBus-MS or relay-MS cards (SNMP/manageable)
Selectable Efficiency Mode	Yes (selectable high efficiency mode)
Certifications / Compliance	CB RCM CE IEC/EN 62040-1 IEC/EN 62040-2 EN 62040-3 IEC 61000-4 UL 1778 cULus FCC Class B CISPR 22 Class B TUV EAC
Battery Replaceable / Hot-swappable	Yes (hot-swappable)
Communication / Management Interfaces	1 x USB 1 x RS-232 EPO (mini terminal block) Output relay (mini terminal block)
Expandable / Extended Runtime Capability	Yes (optional external battery packs supported via expansion slot/runtime options)

Eaton Eaton 9SX 1500VA/13500W On Line Tower UPS, 240V is a supplier-matched product available from Spot IT. Use this item for compatible business, office, and IT requirements. Manufacturer part number: PW86362. Order online for Australia-wide delivery with local support.
