1000Base-SX Fiber Transceiver (Gbic) Multi-Mode - For All Devices With Sfp Ports Itfztchsx
$197.00
| SKU: | 393082 |
|---|---|
| MPN: | ITFZTCHSX Link |
| Manufacturer: | https://www.1000basesx.com |
| Brand: | Sophos |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
1000Base-SX Fiber Transceiver (GBIC) Multi-Mode - for UTM/SG/XG SFP ports.
Specifications
▼
| SKU | ITFZTCHSX |
|---|---|
| Brand | Sophos |
| Model | ITFZTCHSX |
| Notes | Multiple sellers offer OEM Sophos modules and third‑party compatible, pre-coded/tested units. Verify vendor datasheet/part number for specific electrical and compatibility requirements before purchasing. |
| Weight | 20 g (typical vendor listing); shipping weight varies (e.g., 0.03 kg listed by some vendors) |
| Warranty | Limited lifetime warranty (vendor dependent; some vendors list 5-year warranty & return policy) |
| Connector | LC duplex |
| Data Rate | Supports Gigabit Ethernet (1000BASE); SFP electrical spec 1.25 Gbps |
| Media Type | Multimode fiber (MMF); OM1/OM2/OM3 references provided by vendors |
| Wavelength | 850 nm |
| Description | 1000BASE-SX SFP transceiver (Sophos ITFZTCHSX) provides Gigabit Ethernet connectivity over multimode fiber. Operates at 850 nm with LC duplex connector and supports DOM/DDM for real-time diagnostics. Typical reach is up to 550 m on 50/125 µm OM2 multimode fiber (also supports 220 m on 62.5/125 µm OM1 and longer distances on OM3 as specified by vendor). Fully MSA-compliant and compatible with Sophos equipment and a wide range of MSA/IEEE-compliant switches, routers, NICs and media converters. Commercial operating temperature range 0 to 70°C. Offered as the OEM Sophos module or as third-party compatible replacements (Axiom, OPTCORE, ATGBICS, AddOn, etc.). Limited lifetime warranty (per vendor) and TAA compliance noted for some variants. |
| Form Factor | SFP (mini-GBIC) |
| Applications | Gigabit Ethernet (1G) 1G Fibre Channel Switch-to-switch links Switch-to-NIC or media-converter interfaces Other 1G optical links |
| Manufacturer | Sophos (OEM); multiple third-party manufacturers produce compatible units |
| Max Distance | OM2 (50/125 µm): 550 m OM3 (50/125 µm): Vendor-listed up to 1 km (per specific vendor datasheet) OM1 (62.5/125 µm): 220 m |
| Environmental | Storage Temperature: -40 to 85 °C Operating Temperature: 0 to 70 °C |
| Product Title | Sophos ITFZTCHSX 1000BASE-SX SFP Transceiver (850nm, MMF, LC, 550m, DOM) |
| Receiver Type | PIN (per vendor specifications) |
| DOM/DDM Support | Yes (Digital Optical Monitoring) |
| Extinction Ratio | > 9 dB (vendor-listed) |
| Transceiver Type | 1000BASE-SX (Short Range multimode) |
| Transmitter Type | VCSEL (per vendor specifications) |
| Power Consumption | ≈ 0.8 W (vendor-listed) |
| Receiver Overload | > 0 dBm (vendor-listed) |
| Transmitter Power | -9 to -3 dBm (vendor-listed range) |
| What's in the Box | 1 × SFP transceiver module |
| Compliance Standards | SFP MSA IEEE 802.3z SFF-8472 RoHS CE REACH TAA (noted for some variants) |
| Receiver Sensitivity | < -18 dBm (vendor-listed) |
| Dimensions (L x W x H) | 55.5 × 13.7 × 12 mm (vendor-listed) |
| Regulatory / Trade Codes | ECCN: 5A991 (listed by some vendors) HTS Code: 85176200 / 8517.62.0090 (vendor-listed variants) |
| Manufacturer Part Numbers | ITFZTCHSX (Sophos OEM) ITFZTCHSX-AX (Axiom) OSP1250-8505DCR (OPTCORE) ITFZTCHSX-AO (AddOn) Other vendor-specific compatible P/Ns |
| Alternate / Compatible Brands | Axiom OPTCORE ATGBICS AddOn Many MSA-compliant OEM transceivers (Cisco, Juniper, HP, Dell, etc.) |
Vendor Info
▼
1000Base-SX Fiber Transceiver (GBIC) Multi-Mode - for all devices with SFP ports
