StarTech.com Transceiver/Media Converter - Taa Compliant - 2 Port(s) - 1 X Network (Rj-45) - 1 X Sc - Duplex Sc Port - Optical Fiber, Twisted Pair - Single-mode - 1310 Nm Fiber - Fast Ethernet - 10/100Base-TX, 100Base-FX - 30 Km - Ac Adapter - Desktop, R
ack-mountable ET90110SM302
$332.00
| SKU: | 200710 |
|---|---|
| MPN: | ET90110SM302 Link |
| Manufacturer: | http://www.startech.com/au |
| Brand: | Startech |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | Preorder 2-3 weeks |
| Fright Estimate |
Description
▼
The ET90110SM302 10/100 Mbps Single Mode Fiber Media Converter SC (30 km) lets you extend a Fast Ethernet network (10/100) over single mode fiber, at distances up to 30 km (18.6 miles). A cost-effective solution for connecting a 10/100 Mbps Ethernet (10/100Base-T) network to remote network segments over a 100Base-FX fiber backbone, the media converter is designed to offer a durable and convenient Ethernet to fiber solution, with an all-steel chassis, and simple plug-and-play installation with minimal configuration required. For added versatility, this fiber media converter supports standalone operation, or installation into the 20 Slot, 2U Rackmount Chassis (ETCHS2U). Backed by a StarTech.com 2-year warranty and free lifetime technical support. More from the Manufacturer More from the Manufacturer
Specifications
▼
| Product Type | Transceiver/Media Converter |
| Maximum Distance Supported | 30 km |
| Power Source | AC Adapter |
| Form Factor | Desktop, Rack-mountable |
| Network Technology | 100Base-FX, 10/100Base-TX |
| Brand Name | StarTech.com |
| Ethernet Technology | Fast Ethernet |
| USB | No |
| DVI | No |
| Number of Network (RJ-45) Ports | 1 |
| Network (RJ-45) | Yes |
| Number of SC Ports | 1 |
| Media Type Supported | Twisted Pair, Optical Fiber |
| Fiber Mode Supported | Single-mode |
| Total Number of Ports | 2 |
| SC Port Type | Duplex |
| TAA Compliant | Yes |
| Manufacturer Part Number | ET90110SM302 |
| Manufacturer Website Address | http://www.startech.com/au |
| Packaged Quantity | 1 Each |
| Manufacturer | StarTech.com |
| Product Name | 10/100 Mbps Single Mode Fiber Media Converter SC 30 km |
| Parallel Port | No |
| Digital Audio | No |
| Digital Audio/Video | No |
| Fiber Optic Cable Wavelength | 1310 nm |
| Compatibility | ETCHS2U Rackmount Chassis |
| Certifications & Standards | • IEEE 802.3 • IEEE 802.3u • FC • FCC |
| Environmentally Friendly | Yes |
| REACH Declaration URL | https://media.startech.com/cms/pdfs/et90110sm302_rohs.pdf |
| EU RoHS Declaration URL | https://media.startech.com/cms/pdfs/et90110sm302_rohs.pdf |
| End of Life Manual Availability | Yes |
| REACH free of SVHC | Yes |
| WEEE Statement | https://media.startech.com/cms/pdfs/et90110sm302_weee.pdf |
| Weight (Approximate) | 391.2 g |
| Height | 22.9 mm |
| Width | 86.4 mm |
| Depth | 154.9 mm |
| Product Color | Black |
| Color Family | Black |
| Input Voltage | 12 V DC |
| Power Consumption | 19.20 W |
| Plug/Connector Type | Type M |
| Shipping Dimensions | Height 9.3, Width 14, Length 20.7, Shipping Weight 0.76 KG |
Vendor Info
▼
StarTech.com Transceiver/Media Converter - TAA Compliant - 2 Port(s) - 1 x Network (RJ-45) - 1 x SC - Duplex SC Port - Optical Fiber, Twisted Pair - Single-mode - 1310 nm Fiber - Fast Ethernet - 10/100Base-TX, 100Base-FX - 30 km - AC Adapter - Desktop, Rack-mountable
