    Tp-link Eap110-outdoor 300mbps Wireless N Outdoor Access Point Eap110-outdoor

    $83.00
    SKU:246222
    MPN:EAP110-OUTDOOR Link
    Manufacturer:http://www.tp-link.com/
    Brand: Tp-link
    Warranty:Standard Manufacturer's Warranty
    Availability:

    Preorder 2-3 weeks

    Fright Estimate
    Add to Compare

    300Mbps Wireless N Outdoor Access PointEAP110-Outdoor

    • Built for outdoor Wi-Fi applications
    • Up to 300Mbps Wi-Fi with 2x2 MIMO technology
    • High transmission power and high gain antennas provide a long-range coverage area
    • Durable, weatherproof enclosure to withstand fair and foul weather
    • Passive PoE(Power over Ethernet) support and simple mounting design allow for flexible deployment and convenient installation
    • Free Auranet Controller Software lets administrators easily manage hundreds of EAPs
    • Captive portal provides a convenient method for guest authentication
    • Supports management vlan for an enhanced network management

    Enjoy Wi-Fi Outside, Finally

    EAP110-Outdoor

    Swimming
    Pool

    Outdoor
    Events

    Gardens

    Weatherproof Enclosure with IP65 Certification

    Rated as IP65 during Ingress Protection testing, a resilient weatherproof enclosure protects the access points against harsh outdoor condition.

    •  Casing made from durable ASA material
    •  Specialized waterproof antennas


    6KV Lightning Protection and
    15KV ESD Protection



    No Ingress of Dust



    Water Proof Enclosure

    Wi-Fi That Goes the Distance

    With high transmission power and two high-gain omnidirectional antennas,
    EAP110-Outdoor provides stable wireless coverage at a range of up to 200 meters in outdoor settings.

    200m

    • High Transmission Power
    • High-Gain Antennas
    Supports Passive PoE
    for Easy Outdoor Set up

    Do away with DC power adapters and power cords with passive Power over Ethernet (PoE), making outdoor deployment simple and fast.

    Grounded PoE Adapter

    Up to 60m
    Flexible
    Installation Options

    Secure access points to walls or poles with the mounting kits provided.

    Efficient Network Administration
    in Centrally Managed and Standalone Modes

    Centralized Management

    Manage hundreds of access points at once with the multi-function Auranet Controller software, ideal for small and medium-sized business networks.

    Learn more

    Auranet Controller Software

    • Wireless N Speed up to 300Mbps
    • Simple mounting design makes easy to install on any wall or pole
    • Passive PoE supported for convenient and affordable installation
    • Weatherproof enclosure, 15KV ESD and 6KV lightning protection
    • Free Controller Software for easy centralized management of hundreds of EAPs
    • Captive portal provides one convenient method of authentication for Wi-Fi guests
    • Rate limit on per SSID to restrict the bandwidth of each client
    • Load balance ensures large numbers of users have smooth network experiences in high density business networks
    • Access Control restricts or only allows the client to access the specified network segment
    • Reboot Schedule enables all the APs to reboot automatically at a specified time
    • WPA/WPA2-enterprise, 802.1X with RADIUS secure authentication and rogue access point detection ensure the security of WLAN
    • Multi-SSID divides multiple wireless network for different users
    • Multiple operating modes including managed AP and standalone AP satisfy different application conditions
    HARDWARE FEATURES
    Interface Fast Ethernet (RJ-45) Port *1（Support Passive PoE）
    Button Reset
    Power Supply 24VDC / 0.6A Passive PoE Supply
    Power Consumption 6.3 W
    Dimensions ( W x D x H ) 8.2 × 3.7 × 1.7 in. (209 × 95 × 42.6 mm)
    Antenna Type 2*5dBi External Omni waterproof
    Mounting Pole / Wall Mounting (Kits included)
    Watch Dog Yes
    WIRELESS FEATURES
    Wireless Standards IEEE 802.11n/g/b
    Frequency 2.4GHz
    Signal Rate 11n: Up to 300Mbps(dynamic)
    11g: Up to 54Mbps(dynamic)
    11b: Up to 11Mbps(dynamic)
    　
    Transmit Power CE：
    <20dBm
    FCC:
    <27dBm
    　
    Wireless Functions Multiple SSIDs（Up to 8 SSIDs）
    Enable/Disable Wireless Radio
    Automatic Channel Assignment
    Transmit Power Control （Adjust Transmit Power on dBm）
    QoS(WMM)
    Load Balance
    Rate Limit
    Reboot Schedule
    Wireless Schedule
    Wireless Statistics based on SSID/AP/Client
    　
    Wireless Security Captive Portal Authentication
    Access Control
    Wireless Mac Address Filtering
    Wireless Isolation Between Clients
    SSID to VLAN Mapping
    Rogue AP Detection
    802.1X Support
    64/128/152-bit WEP / WPA / WPA2-Enterprise,
    WPA-PSK / WPA2-PSK
    　
    MANAGEMENT
    Auranet Controller Software Yes
    Email Alerts Yes
    LED ON/OFF Control Yes
    Management MAC Access Control Yes
    SNMP Yes
    System Logging Local/Remote Syslog Yes
    Telnet Yes
    Web-based Management HTTP/HTTPS
    L3 Management Yes
    Multi-site Management Yes
    Management VLAN Yes
    OTHERS
    Certification CE, FCC, RoHS
    Package Contents 300Mbps Wireless N Outdoor Access Point, EAP110-Outdoor
    Passive PoE Adapter
    Power Cord
    Mounting Kits
    Waterproof Rubber Insert
    Waterproof Antennas
    Installation Guide
    　
    System Requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10
    Environment Operating Temperature: -30℃~65℃ (-22℉~149℉)
    Storage Temperature: -40℃~70℃ (-40℉~158℉)
    Operating Humidity: 10%~90% non-condensing
    Storage Humidity: 5%~90% non-condensing
