Synology DS1825+ 4GB DiskStation 8-Bay Scalable Nas ( Synology Drives Only ) DS1825+
$1,881.00
| SKU: | 228734 |
|---|---|
| MPN: | DS1825+ Link |
| Manufacturer: | https://www.synology.com |
| Brand: | Synology |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
Synology DiskStation DS1825+ is a versatile 8-bay storage solution designed to store and protect mission-critical data. Flexible support for faster networking speeds and capacity expansion makes the DS1825+ ideal for businesses needing a scalable and customizable storage solution for their growing data needs. Powered by Synology DiskStation Manager (DSM), this device is a flexible all-in-one solution for data sharing, synchronization, backup, and surveillance. Backed by Synology's 3-year limited hardware warranty, extendable to 5 years.
Specifications
▼
| UPC | 846504006021 |
|---|---|
| ASIN | B0C8SBXSTJ |
| Fans | 2 x 120 mm |
| Brand | Synology |
| Color | Black |
| Model | DS1825+ |
| BTU/hr | Access: 204.94 BTU/hr HDD Hibernation: 62.54 BTU/hr |
| Weight | Metric: 6 kg (approx.) Imperial: 13.23 lb (reported) |
| Category | Storage |
| Material | Metal, Plastic |
| Warranty | Limited 3-year hardware warranty (extendable with Synology extended warranty options per Synology policy) |
| Base Type | 8-Bay NAS Enclosure |
| CPU Cores | 4 |
| CPU Model | AMD Ryzen V1500B |
| Fan Modes | Full-Speed Mode Cool Mode Quiet Mode |
| USB Ports | 3 x USB 3.2 Gen 1 Type-A (1 front, 2 rear) |
| Drive Bays | 8 |
| CPU Threads | 8 |
| Description | The Synology DiskStation DS1825+ is an 8-bay desktop NAS designed for businesses and advanced users who need scalable, high-performance network storage. Powered by an AMD Ryzen V1500B quad-core 2.2 GHz CPU and 8 GB DDR4 ECC memory (expandable to 32 GB), the DS1825+ includes dual built-in 2.5GbE ports, a PCIe Gen3 x8 (operates at x4 link) slot for 10/25GbE adapters, two M.2 2280 NVMe slots (for cache or storage), and support for up to two DX525 expansion units to reach 18 drive bays and up to 360 TB raw capacity. Synology DiskStation Manager (DSM) provides file sharing, backup, synchronization and surveillance features. Note: several sources report Synology enforces validated-drive and validated-PCIe-card compatibility for storage pools (Synology-validated HDDs and NVMe SNV-series SSDs noted). |
| Noise Level | 23.8 dB(A) (reported) |
| CPU Quantity | 1 |
| Memory Notes | Synology recommends Synology-branded ECC memory; non-Synology modules may trigger warnings or affect warranty/support. For multi-module configurations, modules should be identical. |
| Memory Slots | 2 |
| Power Supply | 250 W external power adapter |
| Sub-Category | Network Attached Storage (NAS) |
| CPU Frequency | 2.2 GHz |
| Network Ports | 2 x 2.5GbE RJ-45 (supports link aggregation/failover); supports 10GbE SFP+/RJ-45 and 25GbE SFP28 adapter cards via PCIe |
| Product Title | Synology DiskStation DS1825+ 8-Bay NAS Enclosure |
| Certifications | FCC CE BSMI VCCI RCM UKCA EAC CCC KC BIS RoHS |
| Drive Bay Types | Front: 3.5"/2.5" SATA (hot-swappable) |
| Expansion Ports | 2 x USB Type-C (for DX525 expansion units) |
| M.2 Drive Slots | 2 x M.2 2280 NVMe (PCIe Gen3 x4) — for cache or storage (sources note SNV-series NVMe support reported) |
| AC Input Voltage | 100–240 V AC, 50/60 Hz, single phase |
| CPU Architecture | 64-bit (x86, embedded server-class) |
| Storage Humidity | 5% to 95% RH |
| Operating Humidity | 8% to 80% RH (operating) |
| PCIe Expansion Slot | 1 x PCIe Gen3 x8 physical slot (operates at x4 link) |
| Storage Temperature | -20°C to 60°C (-5°F to 140°F) |
| Included Accessories | Main unit x1 Accessory pack x1 AC power cord x1 RJ-45 LAN cable x2 |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Supported Drive Types | 3.5" SATA HDD, 2.5" SATA SSD, M.2 2280 NVMe SSD |
| Supported RAID Levels | JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10 (per product specs) |
| Dimensions (H x W x D) | Metric: 166 mm x 343 mm x 243 mm Imperial: 6.54 in x 13.5 in x 9.57 in |
| Maximum Memory Capacity | 32 GB (2 x 16 GB) |
| Hot-Swappable Drive Bays | 8 (front) |
| Manufacturer Part Number | DS1825+ |
| Storage Operating System | Synology DiskStation Manager (DSM); reported DSM 7.3.x available |
| Drive Compatibility Notes | Multiple sources report Synology enforces validated-drive compatibility for storage pools and restricts supported HDDs/SSDs and some PCIe cards to Synology-validated models. |
| Other Features (reported) | Easy replacement system fan LED indicators (brightness adjustable reported) Power recovery Scheduled power on/off Kensington security slot (cable lock sold separately) Hardware encryption Face/Object recognition features (reported via DSM packages) |
| System Memory (Installed) | 8 GB DDR4 ECC SO-DIMM (1 x 8 GB) |
| Hardware Encryption Engine | AES-NI (supported) |
| Power Consumption (Access) | 60.1 W (reported) |
| Identifiers / Additional Notes | B&H #: SYDS1825P MFR #: DS1825+ Notes: Multiple sources report Synology enforces validated-drive and validated-PCIe-card compatibility; verify supported drive and card lists before deployment. Performance numbers (throughput, power, noise) may vary by workload, drives installed, and network configuration. Manufacturer: Synology Model Series / Item Model Number: DS1825+ |
| IP Camera Compatibility / Video | Compression Formats: [ "H.264", "H.265" ] Image Resolution (example noted): 1920x1080 (reported) |
| Maximum Supported Capacity (Raw) | Up to 360 TB (with expansion) |
| Maximum Drive Bays (with expansion) | 18 (with up to two DX525 expansion units) |
| Supported Protocols / Network Services | SMB/CIFS, AFP, NFS v3/v4/v4.1, FTP, WebDAV, iSCSI, Rsync, ACL, VPN Server; supports Wake on LAN/WAN (per sources) |
| Surveillance / Camera Support (reported) | Up to 40 IP cameras (per source) |
| Optional / Compatible Accessories (reported) | DDR4 ECC SODIMM: D4ES03-8G / D4ES03-16G Expansion Unit: DX525 Enterprise 3.5" SATA HDD: HAT5300 Series Plus Series 3.5" SATA HDD: HAT3300 Series Enterprise 2.5" SATA SSD: SAT5200 Series Enterprise M.2 2280 NVMe SSD: SNV3400 & SNV5400 Series 25GbE NIC: E25G30-F2 10GbE NICs: E10G30-F2 / E10G30-T2 / E10G18-T1 |
| Power Consumption (HDD Hibernation / Standby) | 18.34 W (reported) |
