INPUT

Generator Compatibility

Yes

Nominal Input Voltage ( Vac )

220

230

240

Input Voltage Range ( Vac )

159 ~ 288

Adjustable Voltage Range ( Vac )

151 ~ 302 Vac

Input Frequency ( Hz )

50 ± 3

60 ± 3

Input Frequency Detection

Auto-sensing

Input Connector Type

IEC C20

Detachable Power Cord Plug Type

IEC C20
Schuko
UK

Power Cord Length (ft.)

8

Power Cord Length (m.)

2.4

OUTPUT Capacity (VA)
3000
Capacity (Watts)
3000
On Battery Waveform
Pure Sine Wave
On Battery Voltage(s) ( Vac )
220 ± 5%
230 ± 5%
240 ± 5%
On Battery Frequency ( Hz )
50 ± 1%
60 ± 1%
Power Factor
1
Automatic Voltage Regulation (AVR)
Double Boost, Single Buck
Overload Protection
Internal Current Limiting , Circuit Breaker
Outlet(s) - Total
8
Outlet Type
IEC C13 x 6 　
IEC C19 x 2 　
Outlet(s) - Battery & Surge Protected
8
Outlet(s) - Critical Load (CL)
4
Outlet(s) - Non-Critical Load (NCL)
4
Typical Transfer Time ( ms )
4
BATTERY Runtime at Half Load ( min )
7.1
Runtime at Full Load ( min )
1.7
Typical Recharge Time ( Hours )
3
Start On Battery
Yes
Built-in Battery Management Module
Yes
User-replaceable
Yes
Hot-swappable
Yes
Battery Type
Sealed Lead-acid
Replacement Battery Pack
RBP0129
RBP Quantity ( pcs )
1
Extended Battery Module (EBM)
BP48VP2U02 (Built-in Charger)
Max. EBM Quantity ( pcs )
Unlimited
SURGE PROTECTION & FILTERING Surge Suppression ( Joules )
2430
EMI/RFI Filtration
Yes
Network Protection RJ45
1-in, 1-out
MANAGEMENT & COMMUNICATIONS LCD Panel
Yes
LCD Orientation
Rotatable LCD panel
LCD Information Display
Operation Type , Power Status , Battery Status , Load Status , Fault & Warning , Other Information , Event & Log
LCD Setting & Control
Mode Setting , Alarm Setting , Input & Output , Battery Setting , Communication , Language
LED Indicators
Power On , Line Mode , Battery Mode , UPS Fault , Night Mode
HID Compliant USB Port(s)
1
Serial Port
RS232
Dry Contact (with Relay)
Yes
Emergency Power Off (EPO) Port
Yes
Audible Alarms
Battery Mode , Low Battery , Overload , Overcharge , Overheat
Management Cable ( pcs )
USB Cable x1 , Serial Cable x1 , EPO Cable x1
Power Management Software
PowerPanel® Business
SNMP/HTTP Remote Monitoring
Yes - with optional RMCARD205
PHYSICAL Form Factor
Rack/Tower
Enclosure Construction
Metal
Color
Black
Rackmount Rail
Yes
Rackmount Ears
Yes
PHYSICAL SIZE - UPS MODULE Dimensions (WxHxD) (in.)
17.1 x 3.4 x 19.7
Dimensions (WxHxD) (mm.)
433 x 86.5 x 500
Weight (lbs.)
72.3
Weight (kg.)
32.8
Installed Rack Height ( U )
2
SHIPPING DIMENSIONS Dimensions (WxHxD) (in.)
22.1 x 10.8 x 24.4
Dimensions (WxHxD) (mm.)
560 x 275 x 620
Weight (lbs.)
90
Weight (kg.)
40.8
ENVIRONMENTAL Operating Temperature (°F)
32 ~ 104
Operating Temperature (°C)
0 ~ 40
Operating Relative Humidity (Non-condensing) ( % )
0 ~ 95
Operating Elevation ( feet/meters )
0-10,000 feet (0-3,000 meters)
Storage Temperature (°F)
5 ~ 113
Storage Temperature (°C)
-15 ~ 45
Storage Relative Humidity (Non-condensing) ( % )
0 ~ 95
Storage Elevation ( feet/meters )
0-50,000 feet (0-15,000 meters)
CERTIFICATIONS Certifications
CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2
RoHS
Yes
