UA-HUB-DOOR-MINI – Compact Access Control Hub for a Single Door
The UniFi Access Door Hub Mini is a compact, DIN-rail-mountable access control hub designed to manage a single door within the UniFi Access ecosystem. It supports PoE++ input and provides two PoE outputs for powering connected devices such as readers and locks. With built-in dry contact relays, door position, and exit request inputs, it offers a complete solution for secure entry and exit control.
Ideal for indoor installations, the UA-Hub-Door-Mini is UL 294 certified, NDAA compliant, and integrates seamlessly with UniFi Access software for centralized management.
Key Features:

Controls 1 door with entry and exit logic
(1) PoE++ input, (2) PoE outputs (30W each, 45W max combined)
(3) GbE RJ45 ports for networking
Dry contact relay: 30V DC, 1A
Inputs: door position sensor, exit request
DIN-rail mountable (included)
Indoor use only (0–40°C operating range)
Max power consumption: 50W (with PoE output)
UL 294 and CAN/ULC-60839-11-1 certified
NDAA compliant
