ASUS ROG STRIX X570-E GAMING WIFI II AMD X-570 ATX Motherboard with PCIe 4.0, 12+4 power stages, and WiFi 6E (802.11ax)

Special Price $478.00 Regular Price $550.00
SKU:377919
MPN:ROG STRIX X570-E GAMING WIFI II Link
Manufacturer:https://www.asus.com/au/
Brand: Asus
Warranty:Standard Manufacturer's Warranty
Availability:

In stock

Fright Estimate

CPU

AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3000 Series/ 3000 G-Series/ 2000 Series/ 2000 G-Series Desktop Processors
* Refer to www.asus.com for CPU support list.

Chipset

X570

Memory

AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors

4 x DIMM, Max. 128GB, DDR4 4600(O.C.)/4400(O.C.)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3733(O.C.)/3600(O.C.)/3466(O.C.)/3400(O.C.)/3200/3000/2933/2800/2666/2400/2133, un-buffered memory

AMD Ryzen™ 5000 and 4000 G-Series Processors

4 x DIMM, Max. 128GB, DDR4 5100(O.C)/4800(O.C.)/4600(O.C)/4466(O.C.)/4400(O.C)/4266(O.C.)/4133(O.C.)/4000(O.C.)/3866(O.C.)/3600(O.C.)/3466(O.C.)/3200/3000/2800/2666/2400/2133, un-buffered memory

AMD Ryzen™ 2000 Series Desktop Processors

4 x DIMM, max. 128GB, DDR4 3600(O.C.)/3466(O.C.)/3400(O.C.)/3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133, un-buffered memory

AMD Ryzen™ 2000 and 3000 G-Series Desktop Processors

4 x DIMM, max. 128GB, DDR4 3200(O.C.)/3000(O.C.)/2933/2800/2666/2400/2133, un-buffered memory

Dual Channel Memory Architecture

ECC Memory (ECC mode) support varies by CPU.

* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory frequency support depends on the CPU types.

Graphics

1 x DisplayPort

1 x HDMI® port

- Supports HDMI 2.0b with maximum resolution of 4096 x 2160 @ 60 Hz

- Supports DisplayPort 1.2 with max. resolution 4096 x 2160 @ 60 Hz

* VGA resolution support depends on processors' or graphic cards' resolution. For more details about the video input and output settings please refer to the user manual.

Expansion Slots

AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors

2 x PCIe 4.0 x16 (x16 or dual x8)*

AMD Ryzen™ 5000 G Series/4000 G-Series/ 2000 Series Processor

2 x PCIe 3.0 x16 (x16 or dual x8)*

AMD Ryzen™ 2000 G-Series/ 3000 G-Series Processor

1 x PCIe 3.0 x16 (x8 mode)*

AMD X570 Chipset

1 x PCIe 4.0 x16 slot (supports x4 mode)

2 x PCIe 4.0 x1

*PCIeX16_3 slot shares bandwidth with PCIeX1_2.

Storage

Supports 2 x M.2 slots and 8 x SATA 6Gb/s ports

AMD Ryzen™ 5000 Series/ 3000 Series Desktop Processors:

M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)

AMD Ryzen™ 5000 G-Series/4000 G-Series/ 3000 G-Series/ 2000 G-Series/2000 Series Processor

M.2_1 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes)

AMD X570 Chipset

M.2_2 slot (Key M), type2242/2260/2280/22110 (supports PCIe 4.0 x4 & SATA modes)

8 x SATA 6Gb/s ports

Supports RAID 0, 1, 10

Ethernet

1 x Intel® 1Gb Ethernet

1 x Realtek 2.5Gb Ethernet

1 x Intel® I211-AT 1Gb Ethernet

Anti-surge LANGuard

ROG GameFirst Technology

Wireless & Bluetooth

Wi-Fi 6E

2x2 Wi-Fi 6E (802.11 a/b/g/n/ac/ax)

Supports 2.4/5/6GHz frequency band*

Bluetooth v5.2

* WiFi 6E 6GHz regulatory may vary between countries, and function will be ready in Windows 11 or later.

USB

Rear USB:Total 8 ports

AMD RyzenTM 5000, 5000 G-Series, 4000 G-Series, and 3000 Series Desktop Processors

- 4 x USB 3.2 Gen2 ports (4 ports at back panel, Type-A)

AMD RyzenTM 3000 G-Series, 2000, and 2000 G-Series Desktop Processors

- 4 x USB 3.2 Gen 1 ports (4 ports at back panel, Type-A)

AMD X570 chipset

- 1 x USB 3.2 Gen2 front panel connector

- 4 x USB3.2 Gen2 (at back panel, 3x Type-A, 1x Type-C)

- 2 x USB3.2 Gen1 ports (at front panel)

- 4 x USB 2.0 ports (at front panel)

Front USB:Total 7 ports


Audio

Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC*

- Impedance sense for front and rear headphone outputs

- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers

- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking

- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)

- Supports up to 32-Bit/192 kHz playback*

Audio Features

- SupremeFX Shielding Technology

- Gold-plated audio jacks

- Rear optical S/PDIF out port

- Premium audio capacitors

- Audio cover

* Due to limitations in HDA bandwidth, 32-Bit/192 kHz is not supported for 7.1 Surround Sound audio.
