Buy MS105GP TP-LINK MERCUSYS MS105GP 5-PORT GIGABIT DESKTOP SWITCH WITH 4-PORT POE+, 5YR WTY

TP-LINK MERCUSYS MS105GP 5-PORT GIGABIT DESKTOP SWITCH WITH 4-PORT POE+, 5YR WTY MS105GP

$55.00

SKU:	407244
MPN:	MS105GP Link
Manufacturer:	https://www.tp-link.com
Brand:	Tplink
Warranty:	Standard Manufacturer's Warranty
Availability:	In stock
Fright Estimate

▼

Full Gigabit Ports: Five gigabit augo-negotiation ports provide up to 10 Gbps switching capacity.
65 W PoE Budget: Four gigabit 802.3af/at-compliant PoE+ ports easily connect and power fixed devices like IP cameras, access points, and IP phones via a single cable. Up to 30 W PoE output is supported by each PoE port.*
Up to 250 m PoE Transmission: With Extend Mode, PoE transmission distance reaches up to 250m, perfect for surveillance camera deployment in large areas.**
PoE Auto Recovery: Automatically reboots your dropped or unresponsive PoE-powered devices.
Plug and Play: Simply plug and play for instant connectivity with no configuration required.
Silent Operation: Fanless design reduces power consumption and ensures silent operation, ideal for noise-sensitive homes or businesses.
Reliable Hardware Design: Durable metal casing and desktop/wall-mounting design are well-suited for different environments.

▼

HARDWARE FEATURES
Interface	• 5× 10/100/1000Mbps RJ45 Ports (Ports 1–4 supports 802.3af/at PoE+) • AUTO Negotiation • AUTO MDI/MDIX
Network Media	• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 100BASE-TX: UTP category 5, 5e cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m) • 1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m); EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity	Fanless
Installation	• Desktop • Wall Mounting
Power Supply	External Power Adapter (Output: 53.5 VDC / 1.31 A)
PoE Ports (RJ45)	• Standard: 802.3 af/at compliant • PoE Ports: Ports 1–4, up to 30 W PoE output per port • Power Supply: 65 W
Dimensions ( W x D x H )	3.9×3.9×1.0 in (99.8×98×25 mm)
Max Power Consumption	• 4 W (220/50 Hz. no PD connected) • 74.46 W (220/50 Hz. with 65 W PD connected)
Max Heat Dissipation	• 13.6 BTU/h (no PD connected) • 253.16 BTU/h (with 65 W PD connected)

SOFTWARE FEATURES
Advanced Features	• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data transmission) • PoE Auto Recovery Button (Ports 1-4) • Compatible With IEEE 802.3af/at Compliant PDs • Mac Address Auto-Learning and Auto-Aging • IEEE 802.3x Flow Control • 802.1p/DSCP QoS • IGMP Snooping • Green Technology
Transfer Method	Store-And-Forward

OTHERS
Certification	FCC, CE, RoHS
Package Contents	• LS105GP • Power Adapter • Installation Guide
Environment	• Operating Temperature: 0–40 ℃ (32–104 ℉); • Storage Temperature: -40–70 ℃ (-40–158 ℉) • Operating Humidity: 10–90% RH non-condensing • Storage Humidity: 5–90% RH non-condensing
