    • Gigabyte Z890 A ELITE WIFI7/ATX/INTEL LGA1851/4x DDR5 DIMM max 256GB/Max 9200MHz/1x PCIE5.0 (CPU), 2xPCIE4.0 (Chipset)/2x M.2 (CPU), 2x M.2(Chipset) GA-Z890-A-ELITE-WIFI7
    main product photo

    Gigabyte Z890 A ELITE WIFI7/ATX/INTEL LGA1851/4x DDR5 DIMM max 256GB/Max 9200MHz/1x PCIE5.0 (CPU), 2xPCIE4.0 (Chipset)/2x M.2 (CPU), 2x M.2(Chipset) GA-Z890-A-ELITE-WIFI7

    $538.00
    SKU:429446
    MPN:M/B Z890 A ELITE WIFI7 1.0
    Manufacturer:https://www.gigabyte.com/
    Brand: Gigabyte
    Warranty:Standard Manufacturer's Warranty
    Availability:

    Preorder 2-3 weeks

    Fright Estimate
    Add to Compare
    Overview

    Key Features

    • Supports Intel® Core™ Ultra processors (Series 2)
    • Digital twin 16+1+2 phases VRM solution
    • D5 Bionic Corsa for Infinite Memory Performance
    • AI Perfdrive : Provides optimal and customized BIOS preset profile for users
    • Premium Compatibility : 4*DDR5 with XMP Memory Module Support
    • WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
    • EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
    • EZ-Latch Click : M.2 heatsinks with screwless design
    • Sensor Panel Link : Onboard video port for hassle-free in-chassis panel setup
    • Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
    • New Power Monitor in HWinfo for real-time monitoring on CPU power phases
    • Ultra-Fast Storage : 4*M.2 slots, including 1* PCIe 5.0 x4
    • Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard L
    • Fast Networking : 2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
    • Extended Connectivity : THUNDERBOLT™ 4 Type-C with DP-Alt, DisplayPort
    • High-Res Audio : ALC1220 & WIMA Audiophile Grade Capacitors
    • Ultra Durable PCIe Armor : The metal back plate of PCIe x16 slot for enhanced durability
    • PCIe UD Slot X : PCIe 5.0 x16 slot with 10X strength for graphics card
    Specifications
    Audio Realtek® ALC1220 CODEC, High Definition Audio, 2/4/5.1/7.1-channel, Support for S/PDIF Out
    Chipset Intel® Z890 Express Chipset
    Form Factor ATX Form Factor; 30.5cm x 24.4cm
    I/O Connectors Back Panel Connectors: 1 x Intel® Thunderbolt™ 4 connectors (USB Type-C® ports), 2 x USB 3.2 Gen 2 Type-A ports (red), 3 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 2 x antenna connectors (2T2R), 1 x DisplayPort, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 2 x audio jacks
    Integrated CPU Graphics Integrated Graphics Processor-Intel® HD Graphics support: - 1 x Intel® Thunderbolt™ 4 connector (USB4® USB Type-C® port), supporting DisplayPort and Thunderbolt™ video outputs When a Thunderbolt™ monitor is installed, the maximum resolution supported is 5120x2880@60 Hz with 24 bpp (single display output). - 1 x front HDMI port, supporting a maximum resolution of 1920x1080@30 Hz - 1 x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
    LAN Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
    PCI Slots CPU: - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16 (PCIEX16) Chipset: - 2 x PCI Express x16 slots, supporting PCIe 4.0 and running at x4 (PCIEX4_1, PCIEX4_2)
    Processor Support LGA1851 socket: Support for Intel® Core™ Ultra Processors
    RAID RAID 0, RAID 1, RAID 5, and RAID 10 support for NVMe SSD storage devices, RAID 0, RAID 1, RAID 5, and RAID 10 support for SATA storage devices
    RAM Type/Bus/Max Support for DDR5 9200(O.C) / 9066(O.C) / 8933(O.C) / 8800(O.C) / 8600(O.C) / 8400(O.C) / 8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) / 6400 / 6200 / 6000 / 5800 / 5600MT/s memory modules; 4 x DDR5 DIMM sockets supporting up to 256 GB (64 GB single DIMM capacity) of system memory; Dual channel memory architecture; Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode); Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules; Support for Extreme Memory Profile (XMP) memory modules; Support CUDIMM memory module
    Socket LGA1851 socket: Support for Intel® Core™ Ultra Processors
    Storage Interface CPU: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 5.0 x4/x2 SSD support) (M2A_CPU) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: - 1 x M.2 connector (Socket 3, M key, type 25110/22110/2580/2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB) - 1 x M.2 connector (Socket 3, M key, type 22110/2280 SATA and PCIe 4.0 x4 SSD support) (M2M_SB) - 4 x SATA 6Gb/s connectors
    Warranty
    Weight
    Wireless & Bluetooth MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.0) - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 - Support for 11be 160MHz wireless standard Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.1) - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency bands - BLUETOOTH 5.4 - Support for 11be 160MHz wireless standard
    Z890 A ELITE WIFI7/ATX/INTEL LGA1851/4x DDR5 DIMM max 256GB/Max 9200MHz/1x PCIE5.0 (CPU), 2xPCIE4.0 (Chipset)/2x M.2 (CPU), 2x M.2(Chipset)
