Dimensions : 394 x 120 x 27mm
Pump Dimension : 80 x 80 x 60mm
Radiator Material : Aluminum
Block Material : Copper
Tube Length : 380mm

Intel 2066, 2011-3, 1366,115x
AMD sTRX4, TR4, AM4

60 x 60mm Full Color LCD

Spec : 120 x 25mm ARGB Fan x 3
Speed : 2500 RPM +/-10%
Bearing Type : 2 Ball Bearing
Air Flow : 59.25 CFM
Air Pressure : 3.51 mmH2O
Life Expectancy : 70,000 Hours
Noise Level : 18~39.5 dBA

RGB FUSION 2.0 Support
AORUS ENGINE Support

* For the product to fully function, user must install and run both the AORUS ENGINE version 1.81 and RGB FUSION 2.0 version B20.0110.1 software.

3 Years

1. The TR4 mounting bracket is bundled with TR4 CPU Package, not in the AORUS package.
2. PSU must use a 5pin SATA power cable with 3.3V output to support LCD image display.
3. Custom image: Support BMP only, image width under 820 pixels. AORUS ENGINE will crop a 320x320 pixel image from the full image.
4. Custom text: Support English letters and numbers input only.
5. OS Windows 10 recommended.
6. AORUS LIQUID COOLER 360 compatible with all MB brands.
