INOVONICS 1 INPUT UNI TRANS - EOL SUP 3MIN 3YR EN1210EOL
$102.00
| SKU: | 406142 |
|---|---|
| MPN: | EN1210EOL Link |
| Manufacturer: | https://www.inovonics.com/ |
| Brand: | INOVONICS |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
The Inovonics EN1210EOL single input universal with EOL is a universal transmitter with an end of line resistor. The included 2.2k ohm resistor is required to operate the EN1210EOL.
Key Features
- Mounting bracket included for quick and easy installation
- Can be used with almost any standard NO/NC contact
- Fully supervised
- Includes case tamper protection
Specifications
▼
| Dimensions: | 8.9 x 4.3 x 2.3 cm |
| Weight: | 54g |
| Typical battery life: | 3-5 years |
| Internal battery type: | Panasonic CR123A |
| External contacts: | Normally open or normally closed |
| External contact cabling requirements: | 14-22 gauge wire, unshielded |
| Distance, external contact to trasmitter: | 3m maximum |
| Temperature: | -20 to 60°C |
| Humidity: | Up to 90% (non-condensing) |
| Market: | North America, Australia, New Zealand |
| EchoStream® frequency: | 902-928 MHz, frequency hopping spread spectrum |
| Check-in time frequency: | 3 minutes |
| Regulatory compliance: | FCC, ISED, RCM, RoHS |
