Chenbro RM42300 Black 4U Rackmount Case, No Psu, 2x USB 2.0, External 3x 5.25",Internal 4x 3.5", 1x Slim Odd Slot, 1x 120mm Fan RM42300H02
$404.00
| SKU: | 381322 |
|---|---|
| MPN: | RM42300H02 Link |
| Manufacturer: | https://www.chenbro.com |
| Brand: | Chenbro |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
4U 17.5" Compact Industrial Server Chassis
With entire isolated anti-vibration cage, dust-proof filter, and compact size make it perfect for space-sensitive industrial applications.
Features & Benefits
-Supports M/B up to 12” x 9.6”
-Available for rackmount and stand-alone installation
-Dedicated 80 mm fan for HDD cooling
-Truly isolated anti-vibration design on internal HDD and drive cages
-Card retainer to hold low profile and full height add-on cards
-Front 120mm fan with filter for add-on card cooling
Specification
MB Form Factor
ATX (12” x 9.6”)
Dimension (D x W x H)
465.2 x 430.0 x 176.0 (mm)
Drive Bay
External 3.5"：1
External 5.25"：3
Internal 3.5"：4
Slim ODD：1
PSU Form Factor
PS/2 single
Indicator
1 x Power Status
2 x LAN Activity
1 x HDD Status
Front Control
1 x Power On/Off
1 x System Reset
2 x USB2.0/USB3.0 (Option)
Cooling Fan
Front: 1 x 120 mm (T=25 mm), PWM,
Rear: 2 x 80 mm (T=25 mm) (Option)
System Security
Intrusion Switch (Option)
Key Lock on Front Door
Expansion Slot Opening
7 x Full Height
Net Weight
9.5 kg/20.93 lb
Gross Weight
12.3 kg/27.09 lb
With entire isolated anti-vibration cage, dust-proof filter, and compact size make it perfect for space-sensitive industrial applications.
Features & Benefits
-Supports M/B up to 12” x 9.6”
-Available for rackmount and stand-alone installation
-Dedicated 80 mm fan for HDD cooling
-Truly isolated anti-vibration design on internal HDD and drive cages
-Card retainer to hold low profile and full height add-on cards
-Front 120mm fan with filter for add-on card cooling
Specification
MB Form Factor
ATX (12” x 9.6”)
Dimension (D x W x H)
465.2 x 430.0 x 176.0 (mm)
Drive Bay
External 3.5"：1
External 5.25"：3
Internal 3.5"：4
Slim ODD：1
PSU Form Factor
PS/2 single
Indicator
1 x Power Status
2 x LAN Activity
1 x HDD Status
Front Control
1 x Power On/Off
1 x System Reset
2 x USB2.0/USB3.0 (Option)
Cooling Fan
Front: 1 x 120 mm (T=25 mm), PWM,
Rear: 2 x 80 mm (T=25 mm) (Option)
System Security
Intrusion Switch (Option)
Key Lock on Front Door
Expansion Slot Opening
7 x Full Height
Net Weight
9.5 kg/20.93 lb
Gross Weight
12.3 kg/27.09 lb
Specifications
▼
| MB Form Factor | ATX (12” x 9.6”) |
| Dimension (D x W x H) | 465.2 x 430.0 x 176.0 (mm) 18.32” x 16.93” x 6.93” |
| Drive Bay | External 3.5"：1 External 5.25"：3 Internal 3.5"：4 Slim ODD：1 |
| Storage Backplane | N/A |
| PSU Form Factor | PS/2 Single or 1+1 Redundant |
| Indicator | 1 x Power Status 2 x LAN Activity 1 x HDD Status |
| Front Control | 1 x Power On/Off 1 x System Reset 2 x USB2.0/USB3.0 (Option) |
| Cooling Fan | Front: 1 x 120 mm (T=25 mm), PWM, Rear: 2 x 80 mm (T=25 mm) (Option) |
| System Security | Intrusion Switch (Option) Key Lock on Front Door |
| Expansion Slot Opening | 7 x Full Height |
| Net Weight | 9.5 kg/20.93 lb |
| Gross Weight | 12.3 kg/27.09 lb |
| Cubic Feet | 3.44 |
| Container Loading (Single Packing) | 20': 192 , 40': 432 , 40'H: 504 (Single + Pallet) |
Vendor Info
▼
Chenbro RM42300 Black 4U Rackmount Case, No PSU, 2x USB 2.0, External 3x 5.25",Internal 4x 3.5", 1x Slim ODD Slot, 1x 120mm Fan
