AJAX KEYPAD TOUCHSCREEN WIRELESS BLACK 2Y 58468.148.BL3
$477.00
| SKU: | 432309 |
|---|---|
| MPN: | 58468 |
| Brand: | AJAX |
| Warranty: | Standard Manufacturer's Warranty |
| Availability: | In stock |
| Fright Estimate |
Description
▼
Wireless keypad with touch screen to control an Ajax system
KeyPad TouchScreen combines security and smart home device management. With an intuitive interface, multiple language options, and smartphone-like familiarity, it's easy to use. The large display, DESFire technology, and code options ensure a secure and efficient experience.
Two power options
Up to 1.5 years of operation on batteries
External power supply 12 V⎓ + batteries as a backup power source
Configurable panic buttons
Communication range with an Ajax hub Up to 1,700 m
Grade 2 (EN 50131)
PD 6662:2017
Specifications
▼
| Display | 5", IPS Matrix, 480 x 854 Resolution |
| Sensor type | Capacitive touch |
| Backlight lifetime | 30,000 hours - Guaranteed backlight lifetime when the Always Active Display toggle is enabled. It can be adjusted in Ajax apps and activates only when external power is connected. |
| User interface | Dark and Light modes |
| Key features | Panic buttons, Control, Contactless access, Arm without code, Group managment, Scenario managment, Auto screen wakeup, Remote firmware update |
| Control | Codes, Pass codes, Tag key fobs |
| Access via DESFire® | EV1, EV2 - The technology is based on the ISO 14443 international standard and combines 128-bit encryption and copy protection. |
| Maximum codes | up to 200 personal codes. One code per each user. The number of personal access codes depends on the hub model. |
| Keypad codes | One code per KeyPad. |
| Duress codes | up to 200 personal codes. One code per each user. The number of personal duress codes depends on the hub model. |
| Keypad Duress codes | One code per KeyPad. |
| Codes for unregistered people | up to 99 personal codes. For people who are not registered in the system. The number of such codes depends on the hub model. |
| Sabotage protection | Protection against code guessing. KeyPad locks for 3–180 minutes if an incorrect code is entered more than 3 times in a row within 1 minute. |
| Communications range | up to 1,700 m |
| External Power option | 10.5V–14 V DC - Recommended electrical parameters for the power supply unit are: 12 V DC with a current of at least 0.5 A. |
| Battery | 6 x AA |
| Calculated battery life | up to 1.5 years |
| Dimensions | 172 × 82 × 26 mm |
| Weight | 327 g |
| Operating temperature range | from -10°C to +40°C |
| Operating humidity | up to 75% |
| Warranty | 24 months |
